DN15 (1/2 NB) SCHEDULE 40 ASA150 WELD NECK FLANGE A105N

Outside diameter (O): 88.9mm
Flange thickness (C): 11.1mm
Hub height (X): 30.2mm
Length through hub (A): 21.3mm
Bolt circle diameter (K): 60.4mm
Overall height (Y): 47.7mm
Raised face thickness (RF): 1.5mm
Number of bolt holes: 4
Bolt hole diameter: 15.7mm
Approx. weight: 0.5kg
